AML10 is a 7075 aluminum rod end with a 5/8-18 left-hand thread and a 0.6250 inch bore.

Its aluminum body and self-lubricating race are intended for rods, links, or adjusters that match the listed bore, thread, and rod-end dimensions. This listing includes one rod end; mating hardware is sold separately unless stated otherwise.

Key Specs

• Part Number: AML10
• Product Type: Rod End
• Bearing ID / Bore: 0.625 in
• Bearing OD / Head Diameter: 1.5 in
• Bearing Width / Ball Width: 0.75 in
• Thread Size / Pitch: 5/8-18
• Thread Direction: Left-hand
• Thread Length: 1.625 in
• Centerline Length: 2.625 in
• Misalignment Angle: 16 degrees
• Static Radial Load Rating: 8,600 lb
• Material: 7075 aluminum
• Style: male rod end with self-lubricating race
• Included: One rod end
• Approx. Weight: 0.18 lb

Fitment Notes

Verify thread size, thread direction, bore size, mounting width, and required misalignment before ordering. Final fitment depends on the mating hardware and application geometry.
