COM14T-F1 is a PTFE-lined steel uniball / spherical bearing with a 7/8" inner diameter and 1-9/16" outer diameter.

The supplied COM chart identifies a 52100-steel ball, low-carbon-steel race, and bonded PTFE liner. This listing includes one bearing; cups, retaining rings, misalignment spacers, and mounting hardware are not included.

Key Specs

• Part Number: COM14T-F1
• Product Type: PTFE-lined steel uniball / spherical bearing
• Bearing ID / Bore: 7/8" (0.875 in)
• Bearing OD / Head Diameter: 1-9/16" (1.5625 in)
• Bearing Width / Ball Width: 0.875 in
• Ball Diameter / Ball Radius Reference: 1.312 in ball diameter
• Misalignment Angle: 9.5 degrees
• Static Radial Load Rating: 41,960 lb
• Material: 52100 steel ball; low-carbon steel race
• Finish: heat-treated, hard-chrome-plated ball; oil-coated race
• Style: PTFE-lined COM-T spherical bearing
• Included: One uniball bearing
• Approx. Weight: 0.263 lb

Fitment Notes

Verify bearing ID, OD, width, cup or housing size, spacer stack, and installed width before ordering. Final fitment depends on the housing, spacers, and application-specific hardware.
