This tie rod is a single replacement rod for the Yamaha YXZ1000 MT72 front suspension kit. It is intended for replacing one damaged or bent rod from the matching AVID setup. This listing is for one rod only and is not a complete kit.

Need the complete kit instead of a single replacement rod? View the full kit here:
Yamaha YXZ1000 MT72 72" Front Long Travel Suspension Kit

Key Specifications

• SKU: AVID-YXZ-F-MT72TR
• Pivot style: Adjustable Rod
• Inner pivot: 3/4-16 LHT
• Outer pivot: 5/8-18 RHT
• Overall length: 17.125"
• Make: Yamaha
• Model: YXZ1000
• Kit / application: MT72

Custom Length Options

This rod can be requested from AVID Racing at a shorter custom finished length if needed for a custom application. Contact AVID Racing before ordering to confirm the required finished length, thread engagement, and adjustment range.

Verify the kit, machine application, thread direction, pivot style, and overall length before installation.
